MicroLab and MicroLoop


  • Heart Rate and SPO2 Measurements
  • Spot Check or Continuous Monitoring for up to 60 minutes
  • Audible Signal Quality Warnings for Abnormal Saturation Levels and Heart Rates
  • Results and Trends for Storage and /or Printout
Availability: Available on backorder SKU: MD-SP-00001 Category:
Enquiry Now


Pulse Oximetry

Our easy-to-add pulse oximetry module (36-SPO6000) increases the functionality of the MicroLab and MicroLoop, enhancing their reputation as essential tools for the healthcare professional of today dealing with COPD

Quality and Accuracy

The MicroLab, MicroLoop, and Spirometry PC Software all feature comprehensive calibration check modules for both volume and flow rates, in compliance with ATS/ERS guidelines Accuracy and reproducibility can easily be checked using a 3-liter syringe (36SM2125).

Infection Prevention

The MicroLab and MicroLoop offer the most comprehensive choice today for the prevention of cross-contamination and infection in spirometry The single-use MicroGard (36-MGF1100) bacterial filter ensures all breath samples are filtered of potential contaminates and not released into the environment.

Making Spirometry Easy The highly versatile, intelligent, and beautifully designed MicroLab (36-ML3500MK8) and MicroLoop (36-ML3535-MK8) have been developed with the very latest user-friendly innovations The high-definition color touch screen and stylus to enable the user to navigate the intuitive icon driven menu system with ease. This combination ensures data entry is performed with the advantage of an on-screen language-specific keyboard The portable MicroLab and MicroLoop employ our Gold Standard Turbine measurement technology, which is accurate and reproducible as certified by the ATS (American Thoracic Society), the internationally recognised body for spirometry performance The easy to use and highly reliable MicroLab and MicroLoop are the essential tools for the healthcare professional of today.


MicroLab and Loop

Measurements Forced: FEV1, FVC, PEF, FEV1/FVC, FEV6, VC, FEV.75, FEV3, FEV.75/VC, FEV.75/FVC, FEV1/VC, (FER), FEV3/VC, FEV3/ FVC, FEV.75/FEV6, FEV1/FEV6, FEF25 (MEF75), FEF50 (MEF50), FEF75 (MEF25), FEF25-75 (MMEF), FEF50/ VC, FEF50/FVC, MMEF/FVC (FEF25-75/FVC), FIV1, FIVC, PIF, FIV1/FIVC (FIR), FIF25 (MIF75), FIF50 (MIF50), FIF75 (MIF25), R50 (FEF50/FIF50), MET25-75, FET, MVV (ind)
Relaxed: VT (TV),Ti, Te, Ti/Ttot, EVC, IVC, IC, VT/Ti (TV/Ti), IRV, ERV, FR)
Volume Range: 0.1 to 8 Litres (Gold Standard Turbine 0.1 to 9.99 Litres)
Flow Range: 0.2 to 15 Litres per second
Accuracy: +/- 3% to ATS Recommendations

Spirometry PC Software

Requirements: PC with Microsoft® Windows® 7 32 bit/64 bit, Windows® 8 32 bit/64 bit
Processor/RAM: 1 GHz or above/2 GB
Hard Drive Space: 200MB*
Connection: Two free USB ports – for USB Spirometer and dongle key protection
Video: SVGA 800×600, 256 colour (Recommended 1280 x 1024)

SPo2 Module

SPO2: 0% to 100% +/- 2 digits
Heart Rate: 18-300bpm +/- 1 digit

MicroLab and MicroLoop

  • Full ATS/ERS Compliance
  • High Definition Colour Touch Screen
  • Check Calibration Facility
  • Icon-Driven Menu System
  • Keyboard On-Screen for Easy Data Entry
  • Help Screens with Unique Screen Specific Help Button
  • Real-Time Viewing Capability
  • Quality Checks On Screen for ATS Standards (e.g. Slow Start, Abrupt End, Cough Detected, etc)
  • 2000+ Patient Test Memory
  • 45 Expiratory and Inspiratory Indices Measured (including Relaxed Indices)
  • 20+ Predicted Values
  • Child Incentive Screens (Bubblegum Kid, Milkshake Kid, Wolf)
  • Lung Age Assessment and Result Interpretation by ATS, BTS-NICE or Enright
  • Post Bronchodilator and/or Steroid Assessment Tests
  • Challenge Testing Protocols
  • Direct Connection to External Hewlett Packard Printers
