Handi+ Oxygen Analyzer
The Handi+ Medical Device is a Class II medical device that provides continuous oxygen monitoring. It is designed to deliver safe and effective oxygen therapy to patients in various healthcare settings. The device has been tested with various anesthesia gases, including nitrous oxide, Halothane, Isoflurane, Enflurane, Sevoflurane, and Desflurane, and found to have acceptably low
- FAQs (10)
- Reviews (18)
The Handi+ oxygen analyzer is great for spot-checking O2 percentages in hospitals, clinics, and home care environments. To better meet your oxygen analysis needs, Maxtec has improved the Handi+ O2 analyzer with a simple-to-use, one-touch calibration button, calibration reminder, automatic off, and brand-new overmold. The Handi+ Oxygen Analyzer is a cutting-edge tool designed to offer efficient and reliable measurements of oxygen concentrations. Compact, user-friendly, and highly precise, the Handi+ is an indispensable instrument for medical professionals, health facilities, and those requiring frequent oxygen level monitoring.
- Quick and accurate oxygen concentration measurements.
- One-touch calibration mechanism.
- Extended battery and sensor lifespan.
- Lightweight and easily portable design.
- Safety alerts for deviation from set parameters.
- A new and improved one-touch calibration button
- Durable overmold for extra protection
- Small, convenient, and portable
|Sensor Type||MAX-250 galvanic cell w/Temperature Compensation (Non-Replaceable)|
|Measurement Range||0.0 – 99.9% oxygen (gas)|
|Resolution/Display||0.1% – The three digit LCD indicates values between 0.0 – 99.9% oxygen.
Over range indicated by one decimal point on display located after the first digit
|Response Time||< 15 seconds for 90% step change (at 25°C)|
|Linearity/Accuracy||@ 15° to 40°C. ± 1 % of full scale at constant temperature, R.H. and pressure when
calibrated at full scale; ± 3% actual oxygen level over full operating temperature
|Power||Powered by one internal, non-replaceable, Lithium battery, CR2450. Power on push
button automatically shuts off after 80 seconds time-out. Electronics rated general
purpose; not for use in hazardous areas or for use with flammable gases.
|Battery Life||Approximately 1850 hours (74,000 cycles)|
|Sample Port||M-16 x 1 thread with diverter fitting and barbed tubing adapter|
|Diverter Fitting||Fits medical standard 15mm “T” adapter|
|Operating Temperature||15° to 40°C|
|Storage Temperature||-15° to 50°C|
|Expected Storage Life||Two months. Special freshness seal on sensor.|
|Operating Pressure||Atmospheric pressure to 3psig|
|Environmental||General purpose housing equivalent to NEMA 1. The Handi+ is not waterproof. 0 – 95%
|Weight||Approximately 3 oz. (85 grams)|
|Dimensions||26 × 21 × 15 cm|
Large, easy-to-read, liquid crystal display
New and improved one-touch calibration button
One-touch on and of
Overmold for extra protection
Small, convenient and portable
