CONTEC SP80B Color Display Spirometer with Software and USB
The SP80B Color Display Spirometer is a compact, handheld device designed for comprehensive pulmonary function testing. Utilizing infrared signal acquisition, it accurately measures key respiratory parameters such as Forced Vital Capacity (FVC), Forced Expiratory Volume in one second (FEV1), FEV1/FVC ratio, Peak Expiratory Flow (PEF), and Forced Expiratory Flows at 25%, 50%, 75%, and 25–75% of FVC. These measurements are essential for diagnosing and monitoring conditions like asthma, chronic bronchitis, and other obstructive or restrictive lung diseases.
EMI Plans
Original price was: ₹25,760.₹24,999Current price is: ₹24,999.
Out of stock
Out of stock
Description
The SP80B Color Display Spirometer is a compact, handheld device designed for comprehensive pulmonary function testing. Utilizing infrared signal acquisition, it accurately measures key respiratory parameters such as Forced Vital Capacity (FVC), Forced Expiratory Volume in one second (FEV1), FEV1/FVC ratio, Peak Expiratory Flow (PEF), and Forced Expiratory Flows at 25%, 50%, 75%, and 25–75% of FVC. These measurements are essential for diagnosing and monitoring conditions like asthma, chronic bronchitis, and other obstructive or restrictive lung diseases.
The SP80B features a 2.8-inch color TFT display that presents real-time flow-volume and volume-time graphs, allowing for immediate visual assessment of lung function. It supports both Bluetooth and USB connectivity, enabling seamless data transfer to PCs for further analysis or record-keeping. The device can store up to 9,999 test records, making it suitable for use in hospitals, clinics, and for personal health monitoring. User information such as height, age, and sex can be input to ensure personalized and accurate assessments.
Designed with user convenience in mind, the SP80B operates with a simple one-button measurement process. It includes features like a real-time clock, battery power indicator, and an automatic shutdown function after two minutes of inactivity to conserve battery life. The device is powered by a rechargeable lithium battery, ensuring portability and ease of use in various settings. Its compact dimensions (160 mm × 65 mm × 45 mm) and lightweight design (190g) further enhance its portability. The spirometer comes equipped with essential accessories, including a USB data cable, a mouthpiece, and PC software, providing a comprehensive solution for respiratory health assessment.
Additional information
| Weight | 0.19 kg |
|---|---|
| Dimensions | 16 × 6.5 × 4.5 cm |
| Volume Range | 0 to 10 liters |
| Flow Rate Range | 0 to 16 liters/second |
| Volume Accuracy | ±3% or ±0.05 L |
| Flow Rate Accuracy | ±5% or ±0.2 L/s |
| Display | 2.8-inch LCD |
| Working Current | 200 mA |
| Power Supply | Rechargeable lithium battery |
| Data Storage Capacity | Up to 9,999 test records |
| Connectivity | USB and Bluetooth |
FAQs
Is the SP80B suitable for both clinical and home use?
How does the SP80B display test results?
Can the SP80B store multiple test records?
How is data transferred from the SP80B to a computer?
Does the SP80B require calibration?
What are the power requirements for the SP80B?
Are there any safety features in the SP80B?
| Comprehensive Lung Function Parameters | Measures FVC, FEV1, FEV1/FVC, PEF, FEF25, FEF50, FEF75, FEF25-75. :contentReference[oaicite:6]{index=6} |
| Color Display & Graphical Charts | 2.8″ (or similar) color display with flow-volume and volume-time charts shown. :contentReference[oaicite:7]{index=7} |
| Data Storage & Upload | Stores up to thousands of records, supports data upload via USB or Bluetooth. :contentReference[oaicite:8]{index=8} |
| User Info & Trending | Allows entry of height, age, sex etc., shows trend charts & health state indication. :contentReference[oaicite:9]{index=9} |
| Calibration & Quality Control | Includes calibration function and over-limit prompt for volume/flow to ensure accuracy. :contentReference[oaicite:10]{index=10} |
| Portable, Rechargeable & Lightweight | Rechargeable lithium-battery powered, weight ~190 g, compact for clinics or home use. :contentReference[oaicite:11]{index=11} |
| Automatic Shutdown & Indicators | Auto power-off after ~2 minutes of inactivity; battery indicator and test indicator lights. :contentReference[oaicite:12]{index=12} |
| Spirometer Unit (SP80B) | Main handheld spirometry device with color display. :contentReference[oaicite:1]{index=1} |
| USB Cable | USB data cable for connecting to PC / software. :contentReference[oaicite:2]{index=2} |
| Mouthpiece (Disposable) | One (or more) disposable mouthpiece(s) included for measurement. :contentReference[oaicite:3]{index=3} |
| PC Software | Software for Windows PC to upload/review spirometry data. :contentReference[oaicite:4]{index=4} |
| User Manual / Instructions | Printed or digital user guide for setup, use and maintenance. :contentReference[oaicite:5]{index=5} |
Product details
Made possible by exploring innovative molded plywood techniques, Iskos-Berlin’s Soft Edge Chair blends strong curves with extreme lightness to create a three-dimensionality not usually possible with 2-D plywood.
| Weight | 0.19 kg |
|---|---|
| Dimensions | 16 × 6.5 × 4.5 cm |
| Volume Range | 0 to 10 liters |
| Flow Rate Range | 0 to 16 liters/second |
| Volume Accuracy | ±3% or ±0.05 L |
| Flow Rate Accuracy | ±5% or ±0.2 L/s |
| Display | 2.8-inch LCD |
| Working Current | 200 mA |
| Power Supply | Rechargeable lithium battery |
| Data Storage Capacity | Up to 9,999 test records |
| Connectivity | USB and Bluetooth |
Description
The SP80B Color Display Spirometer is a compact, handheld device designed for comprehensive pulmonary function testing. Utilizing infrared signal acquisition, it accurately measures key respiratory parameters such as Forced Vital Capacity (FVC), Forced Expiratory Volume in one second (FEV1), FEV1/FVC ratio, Peak Expiratory Flow (PEF), and Forced Expiratory Flows at 25%, 50%, 75%, and 25–75% of FVC. These measurements are essential for diagnosing and monitoring conditions like asthma, chronic bronchitis, and other obstructive or restrictive lung diseases.
The SP80B features a 2.8-inch color TFT display that presents real-time flow-volume and volume-time graphs, allowing for immediate visual assessment of lung function. It supports both Bluetooth and USB connectivity, enabling seamless data transfer to PCs for further analysis or record-keeping. The device can store up to 9,999 test records, making it suitable for use in hospitals, clinics, and for personal health monitoring. User information such as height, age, and sex can be input to ensure personalized and accurate assessments.
Designed with user convenience in mind, the SP80B operates with a simple one-button measurement process. It includes features like a real-time clock, battery power indicator, and an automatic shutdown function after two minutes of inactivity to conserve battery life. The device is powered by a rechargeable lithium battery, ensuring portability and ease of use in various settings. Its compact dimensions (160 mm × 65 mm × 45 mm) and lightweight design (190g) further enhance its portability. The spirometer comes equipped with essential accessories, including a USB data cable, a mouthpiece, and PC software, providing a comprehensive solution for respiratory health assessment.
